Next Gear = More Performance
automated multispeed transmission for electric mobility applications
We think about tomorrow
SALA DRIVE GmbH was founded in Grieskirchen, Austria, in 2016 as a merger between several entrepreneurs with more than 40 years’ experience in the automotive, series production and motorsport sectors. The focus is on the development of powertrains for electric mobility applications as well as conventional motors and lightweight components for series production purposes.
Design of Hybrid components
To reduce weight and costs we specialized us in development of Hybrid Components. With this technology we´re breaking limits in the vision of future applications.
E-Mobility
Today, mobility is undergoing a fundamental transformation. The best and most efficient way to clean, CO2-neutral mobility is e-mobility. Multispeed transmission technology for the next level of e-mobility.
Automated multispeed transmission
Electromechanical gear synchronization, which ensures the shortest torque interruptions through optimized torque and speed control of the electric drive during lightning-fast, 0.25-second gear shifts. In this way, any thermal impact by friction elements and possible wear effects on the shift components can be practically eliminated.
Max. input power: 580 kW
Different motors can be flanged to the gearbox, a maximum of 2 left and right, or only one motor left or right
Max. output torque: 7500Nm
The gearbox is suitable for a large number of vehicles. Starting with light and heavy commercial vehicles (7,5t), cars, performance- and sports cars
Mounting position: horizontal or vertical
Integrated oil pump which give us the variability of integrating the gearbox into the drive train
Dimension:535 x 240 x 370 mm
The gearbox has a significantly smaller number of individual components and therefore scores with a considerable reduction in weight and minimal installation space
More amazing details
Ratio 1st gear: 8,14 (can go up to 18)
Very fast switching times can be achieved
Ratio 2ndgear: 4,5 (can go up to 12)
Allow operation in better effiency areas
Max. operating temperature: 110°C
No material wear due to heat
Mass (dry incl. LSD): ~ 54kg
A lightweight in the category transmission systems
Lightwight shifting technology
Zero backlash electric dog clutch
Integrated parking lock
For additional safety requirements
